Specifications

Frequency(Hz): 50
Max. AC output(KVA): 4.5
Rated AC output(KVA): 3.8
Power Factor(cosφ): 1.0
Type: Brush, self-excitation, 2-poles, Single-phase
Voltage Regulator: AVR
DC Output: 12V/8.3A(option)
Engine Model: XY188F
Type: Forced air-cooled, 4-stroke, OHV
Displacement(cc): 389
Max. Output(Hp/rpm): 13.0/3600
Fuel: Unleaded Gasoline
Fuel Tank capacity(L): 22
Continuous Operating Hours(H): 10.0
Oil: SAE 10W30(Above CC grade)
Oil capacity(L): 1.1
Ignition System: T. C. I
Starting System: Recoil
Operating Noise Level (7m) db (A): 72
Net Dimension LXWXH(mm): 674x510x532
Overall Dimension LXWXH(mm): 690x525x550
N. W. /G. W. (kg): 75/78
